Amphenol RF announced the expansion of their robust reverse polarity TNC portfolio with additional configurations designed to accommodate micro-coax cable types including 0.81 mm, 1.13 mm, 1.32 mm dual shielded, 1.37 mm and RG-178. These connectors support frequencies up to 9 GHz and feature a hex shaped body that supports the use of a torque wrench for mating and unmating. RP-TNCs on ultra-flexible micro-coaxial cable types are ideal for industrial, wireless, military and broadband applications.

RP-TNC plugs and jacks are manufactured with nickel plated, brass bodies and gold plated, beryllium copper contacts. They utilize a PTFE insulator similar to existing RP-TNC connectors and offer the same features and benefits customers have come to expect from this durable interface. Front mount bulkhead jack configurations are available which can be fastened on the inside of a panel or enclosure and provides additional security for sensitive systems.

RP-TNCs utilize a familiar threaded interface to ensure mating stability and reliable electrical performance. These RP-TNC connectors join a robust portfolio of reverse polarity RF interconnect available to meet various design requirements across verticals.
