At the IEEE International Solid-State Circuits Conference (IEEE ISSCC 2024), imec presents its low-power ultra-wideband (UWB) receiver chip that is 10x more resilient against interference from Wi-Fi and (beyond) 5G signals than existing, state-of-the-art UWB devices. Imec’s chip is a major step forward in developing and deploying next-generation UWB applications, which are becoming increasingly safety-critical. Think of child presence detection systems in the automotive sector, where reliability and assured availability are paramount, or manufacturing environments, where UWB’s precise localization capabilities could ensure the safety of human workers operating near robotic arms, AGVs and other automated machinery.
In the coming months and years, the spectrum allocated for UWB communications (typically spanning the 6 to 10 GHz frequency range) will face increasing competition from other wireless technologies that eye the same frequencies to extend their reach. The recent approval of Wi-Fi 6e, for instance, positions it to operate in the 5.925 to 7.125 GHz band. And (beyond) 5G technologies are also expanding into the upper 6 GHz band – given that their existing frequency ranges risk running out of steam.
For the UWB industry, this requires proactive measures, especially as UWB technology moves beyond (traditional) secure keyless entry applications to safety-critical automotive and industrial automation functions. In other words, there is a growing need for solutions that allow UWB and other wireless technologies to coexist seamlessly in the same frequency bands.
Imec’s New IR-UWB Receiver
Imec's new impulse radio (IR) UWB receiver chip, implemented in a 22 nm FDSOI process, and with a compact active area of 0.32 mm², stands out as a pioneering solution to avoid interference between UWB and other wireless signals. The receiver has -13 dBm blocker resilience and 7.6 mW power consumption
To enhance the receiver’s blocking performance, a transformer-coupled bandpass filter is integrated into the complementary common gate stage of the UWB low noise amplifier front-end. As such, imec’s receiver exhibits an exceptional -13 dBm blocker resilience, making it 10x more resilient against Wi-Fi and (beyond) 5G interference compared to existing solutions.
Moreover, several circuit design optimizations enable the receiver to achieve its outstanding interference resilience at the lowest power consumption (7.6 mW). This efficiency allows the receiver analog front-end to operate 10x longer on the same (battery) power compared to current IEEE 802.15.4a/z compatible UWB devices, and twice as long as described in recent research papers.
The use of bandpass filters is a widely accepted method for dealing with unwanted signals, such as Wi-Fi, before they enter the receiver. However, imec’s patented implementation to reduce intermodulation distortion significantly increases the receiver's robustness at low power and low supply design.
“To foster its industrial adoption, our UWB receiver not only complies with the existing IEEE 802.15.4z standard; it is also ready to support the upcoming IEEE.802.15.4ab standard. We believe this research, and the underlying collaboration in high-impact industrial ecosystems, are critical steps to enable future wireless technologies to coexist seamlessly across various use cases,” said Christian Bachmann, program director of wireless sensing at imec.
Imec works with industrial partners across the UWB ecosystem through R&D partnerships and IP licensing. Looking ahead, imec is committed to remain at the forefront of UWB innovation. To this end, imec enthusiastically invites companies to join its UWB R&D program and extensive partner network.
Join imec at ISSCC 2024 and discover the new IR-UWB receiver at the imec booth (booth #1).
