pSemi, a Murata Company and leader in mmWave ICs and systems, will demonstrate its new antenna-integrated module (AiM) using a custom-modified MilliBox MBX02 with MilliBox GIM03 positioner.
The pSemi 5G mmWave AiM demo at IMS2022 will highlight:
• Live beamforming, beam steering, and 3D radiation-pattern measurement
• RF patchantenna alignment demonstration
• EVM performance with regard to EIRP
• Accurate calibration of the chamber air gap for EIRP measurements.
David Watling, field applications engineer at pSemi/Murata stated, “I have been using the MilliBox chamber and gimbal for two years. This is a very cost-effective solution and the results have impressed all my customers and colleagues. Its’ use has not just been for demonstrating beam patterns, but also for debugging issues. I have sometimes needed to plot all 16 patch antennas separately which takes many hours of reliable operation, so when I was tasked with demonstrating our 5G mmWave Antenna Module at IMS022, I knew I needed to take my MilliBox with me.”
“We are happy to see that David brought his MilliBox to the IMS2022 show floor, it is a MBX02 that David hacked himself so it stands vertically in order to make it fit in his lab space, he also heavily modified its software to meet his testing requirements” said Jeanmarc Laurent creator of MilliBox, adding: “this really demonstrates everything we wanted MilliBox to be, a solid modular foundation that users can use as-is or tailors it to their specific needs for years of successful testing”
MilliBox use case live demonstrations can be seen throughout IMS2022 Exhibition in Denver Colo., in Copper Mountain Technologies Booth 10036, in NI booth 5020, in pSemi Booth 7078.
To see MilliBox Latest products and meet with MilliBox team visit Booth 7101.
