Smiths Interconnect announces it is extending its broad range of passive components in E-Band with the addition of WR12 coupler, loads and isolators.
Smiths Interconnect’s comprehensive range of broadband WR12 waveguide passive components have been designed for next-generation E-Band terrestrial uplinks to low earth orbit constellations and payloads. Each application has specific environmental demands, and the family of products has been optimized to manage the particularly high RF powers required to sustain a robust communications link.
Tullio Panarello, vice president and general manager of the fiber optics and RF components business unit at Smiths Interconnect, said, “Smiths Interconnect’s proven expertise in waveguide passive component design has resulted in a product series ideal for high reliability applications such as those for prestigious space missions With a full in-house design, manufacturing and testing capability, we work with our customers to ensure that our products meet a specific set of requirements and are rigorously tested and qualified.”
Smiths Interconnect’s E-Band WR12 waveguide hybrids offer the following features:
- Tuneless and broadband, suitable for global applications
- Suitable for signal splitting and combining applications and readily configurable with a selection of high-power termination appropriate to the incident power
- Operating over the allocated band (71 to 76 and 81 to 86 GHz)
- Temperature stable under exacting thermal loads
- Clear chromate conversion coated.
Smiths Interconnect’s WR12 E-Band isolator utilizes a novel design approach selected to be able to handle high levels of forward and reflected RF power and offers:
- Excellent isolation across the 71 to 76 and 81 to 86 GHz bands
- Temperature stable under exacting thermal loads
- Clear chromate conversion coated.
