Global interconnect pioneers Junkosha are using this year’s International Microwave Symposium (IMS), being held between 19 and 24 June, to showcase the core qualities of its new MWX7 Series in environments where significant temperature gradients are experienced across cable assemblies. As increasingly complex 5G and 6G systems are developed, requiring higher frequency bands, so the need for cables with the highest phase stability against temperature become critical.

Rob Sloan, a well-renowned consultant across the microwave industry, explained, “One of the challenges microwave engineers face is that of maintaining phase stability across multiple channels from antennas and sensors, especially in environments where temperature gradients may be experienced across cable assemblies. More complex modulation schemes operating at higher frequencies, likely to be heralded by next generation 5G and 6G systems, will only exasperate this situation. Currently any system requiring phase consistency is affected, whether this is a synthetic aperture radar or a focusing technique; or communications channels employing phased array systems where differential or IQ signaling require invariant phase. Similarly, in network analysis applications where calibration removes systematic errors, a phase change brought on by temperature changes would normally warrant recalibration. Here Junkosha has produced industry leading, low loss, lightweight cables with minimized thermal phase changes associated with the classic ‘Teflon knee.’ These hence reduce the need for recalibration or use of computationally hungry phase correction algorithms.”

Junkosha’s MWX7 series assemblies provide phase stability in multipurpose applications delivering reliable electrical performance, especially in phase and amplitude stability against temperature, to support repeatable measurement results across applications like phased array radars, 5G antennas and automatic test environments. The new ePTFE tape wrapped cable not only offers reduced phase and amplitude drift due to mechanical fluctuations, it also promises consistent performance in both inter and intra batch quality.

Masaru Omoto, product manager for Junkosha, added, “With this new series of cables, we wanted to answer our customers’ need to have a cable that demonstrated the critical requirement of phase stability against temperature, which is vital in an increasing number of applications. Whether its phased array radars, 5G antennas or automatic test environments, changing temperature gradients are an issue that require mitigation. Our ePTFE tape wrapped MWX7 Series has been developed with these scenarios in mind, thereby eradicating the impact of fluctuating temperatures.”
