Vayyar has launched an ultra-short and short-range imaging radar (uSRR/SRR) evaluation kit (EVK) for the development of ADAS and autonomous vehicle applications. Based on Vayyar’s 4D MIMO Radar-on-Chip (RoC), the SRR EVK includes a high-resolution point cloud, with a very wide field-of-view both in azimuth and elevation, no-dead zones and zero minimum distance.

As more scooters, bikes and pedestrians populate the road, there is a growing need for ADAS and monitoring capabilities that can prevent collisions, injuries or deaths. Vayyar’s SRR EVK enables evaluation and development of such applications, delivering a comprehensive radar
hardware-software package for rapid prototyping and experimentation. It features a performance-optimized, automotive grade RoC with a large MIMO array on a compact, single-chip based module. Vayyar’s system supports a high natural resolution and a rich 4D point cloud, without the need for RFIC concatenation.

The kit includes advanced 4D image reconstruction algorithms and software for efficient data representation structures. This allows rich target data streaming to a vehicle central-host-processor over a low bandwidth interface, supporting on-board applications (saving external ECU costs) as well as enabling vehicle-level fusion. Vayyar’s innovative SRR EVK API enables application development, sensor fusion, configuration and data recordings. The GUI provides a 4D display option with support for a side-by-side camera view, for referencing.

Vayyar’s high performance uSRR-SRR technology detects and tracks multiple targets around the vehicle including other vehicles, objects and Vulnerable Road Users, with great accuracy. It includes advanced hardware support for dynamic ranges from 10 cm to 30 m.

This SRR EVK can be used to evaluate and develop Around Vehicle Monitoring, and a host of other ADAS/AV applications including advanced assisted parking, front and rear autonomous emergency braking, front and rear collision warnings, blind spot detection, lane change assist and keyless access systems. It also supports Robotaxi features and meets upcoming NHTSA and EURO NCAP safety requirements.

“With our latest evaluation kit, we are excited to drive a shared mission to make journeys safer for passengers, pedestrians and anyone else on the road. Vayyar’s uSRR/SRR imaging radar is raising the safety standard for ADAS and autonomous vehicles by delivering better ranges and higher 4D resolution for precise detection of the vehicle surroundings,” said Ian Podkamien, head of Vayyar’s Automotive Business Development. “This multi-functional solution addresses both safety and comfort demands, while offering significant cost savings and greatly reducing the number of required ADAS sensors.”

Vayyar’s uSRR/SRR solution is AEC-Q100 and ASIL-B compliant, and ready for SOP’21/22 with high-end, versatile and cost-efficient technology.
