Nano Dimension Ltd. announced that it has developed 3D printed capacitors with the company’s DragonFly additive manufacturing system. These capacitors are embedded in the body of the additively manufactured printed circuit boards (PCB), saving space and eliminating the need for assembly. This discovery in the additive manufacturing of electronics validates the manufacturing applicability of built in capacitors in PCBs printed with the DragonFly system, the only precision additive manufacturing system of its type.

Nano Dimension’s extensive testing with capacitors of different 3D dimensions have shown consistent results with statistically validated data. The repeatability results show less than 1 percent variance. The technology uses the same dielectric and metal traces as in the manufactured PCB yielding capacitors with a capacitance range from 0.1 to 3.2 nF. The successful results are based on over 260 tests with 30 different manufactured capacitors dimensions.

By integrating capacitors using additive manufacturing, electronics designers and manufacturers can avoid what is often a time consuming, multi-step assembly process, as the DragonFly prints the entire capacitor and PCB in one print job. This allows companies to reduce the fabrication time and overcome many of the challenges imposed by traditional production techniques.

Manufacturing capacitors within the inner layers of circuits also can free space to meet the ever-increasing trend towards miniaturization and flatness of electronic devices for consumer, industrial and military applications. With extra space, designers may pack more functionality on the circuit board and shrink component size--all without compromising reliability.

Capacitors of this kind are primarily used to filter electrical noise and ripple voltage for a wide range of applications, including RF transmission lines, audio processing, radio reception and power circuit conditioning.
